APPENDIX I: FACTORY DEFAULT CONFIGURATION I.1 FACTORY DEFAULT SETTINGS
GEK-106310-AF F650 DIGITAL BAY CONTROLLER i-7
Product Setup > Communication Settings > sntp
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Port used UDP port 123 1 [1 : 65535]
IP Address OCT 1 Server IP Oct 1 0 1 [1 : 255]
IP Address OCT 2 Server IP Oct 2 0 1 [1 : 255]
IP Address OCT 3 Server IP Oct 3 0 1 [1 : 255]
IP Address OCT 4 Server IP Oct 4 0 1 [1 : 255]
Product Setup > Communication Settings > procome
Setting Description Name Default Value Step Range
User
Value
Serial Remote Com Port selection COMM Port NONE [NONE – COM1]
Slave number for procome Slave Number 0 [0 : 254]
Product Setup > Communication Settings > ptp 1588
Setting Description Name Default Value Step Range
User
Value
Function permission
PTP FUNCTION DISABLE [DISABLE; ENABLE]
Port A, B Path Delay Adder
PORTA DELAY
ADDER
0 ns [0 : 60000]
Port A Path Delay Asymmetry
PORTA DELAY ASYM 0 ns [-1000 : 1000]
Port B Path Delay Adder
PORTB DELAY
ADDER
0 ns [0 : 60000]
Port B Path Delay Asymmetry
PORTB DELAY ASYM 0 ns [-1000 : 1000]
Strict Power Profile
STRICT POWER
PROFILE
DISABLED DISABLED/ENABLED
PTP domain number
PTP DOMAIN
NUMBER
0 [0 : 255]
PTP VLAN Priority
PTP VLAN PRIORITY 4 [0 : 7]
PTP VLAN Identification
PTP VLAN ID 0 [0 : 4095]
Reference time defining the origin of a time
scale is termed the epoch.
PTP EPOCH UTC SINCE 2000 UTC SINCE 2000; UTC
SINCE 1970; UTC SINCE
1900
Product Setup > Communication Settings > Routing
Setting Description Name Default Value Step Range
User
Value
1st octet of Gateway Default RT GWY Oct1 0 1 [0 : 255]
2nd octet of Gateway Default RT GWY Oct2 0 1 [0 : 255]
3nd octet of Gateway Default RT GWY Oct3 0 1 [0 : 255]
4th octet of Gateway Default RT GWY Oct4 0 1 [0 : 255]
sets the destination IPv4 route Static RT1 IP Oct1 0 1 [0 : 255]
sets the destination IPv4 route Static RT1 IP Oct2 0 1 [0 : 255]
sets the destination IPv4 route Static RT1 IP Oct3 0 1 [0 : 255]
sets the destination IPv4 route Static RT1 IP Oct4 0 1 [0 : 255]
sets the IP mask associated with the route Static RT1 Mask Oct1 0 1 [0 : 255]
sets the IP mask associated with the route Static RT1 Mask Oct2 0 1 [0 : 255]
