I-10 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
I.1 FACTORY DEFAULT SETTINGS APPENDIX I: FACTORY DEFAULT CONFIGURATION
SETPOINT > PRODUCT SETUP > FAULT REPORT
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Positive sequence impedance module Pos Seq Module 3.00
0.01
Ohm
[0.01 : 250.00]
Positive sequence impedance angle Pos Seq Angle 75
1
Deg
[25 : 90]
Zero sequence impedance module Zero Seq Module 9.00
0.01
Ohm
[0.01 : 750.00]
Zero sequence impedance angle Zero Seq Angle 75
1
Deg
[25 : 90]
Line length Line Length 100.0 0.1 [0.0 : 2000.0]
Display fault on HMI Show Fault On HMI DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
CT Direction CT Direction REVERSE NA REVERSE; FORWARD
Setpoint > Product Setup > Oscillography
Setting Description Name Default Value Step Range
User
Value
Function Permission Function ENABLED N/A [DISABLED – ENABLED]
Prefault Trigger Position 30 1% [5 : 95]
Samples per cycle Samples/Cycle 64 N/A [4 – 8 – 16 –32 – 64]
Maximum number of oscillos Max. Number Osc. 4
1
oscill
o
[1 : 20]
Automatic oscillography overwrite Automatic Overwrite DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Product Setup > Data Logger
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Data logger Rate Data Logger Rate 1 s N/A
[1 s, 5 min, 10 min, 15 min,
20 min, 30 min, 60 m
in.]
Data Logger analog channels X Data Logger Chnl X None N/A [1 to 16]
Setpoint > Product Setup > Demand
Setting Description Name Default Value Step Range
User
Value
Function permission Demand Function DISABLED N/A [DISABLED – ENABLED]
Demand method for current values CRNT Demand Method
THERMAL
E
XPONENTIAL
N/A
[BLOCK INTERVAL -
ROLLING DEMAND -
THERMAL EXPONENTIAL]
Demand method for Power values
POWER Demand
Metho
d
THERMAL
EXPONENTIAL
N/A
[BLOCK INTERVAL -
ROLLING DEMAND -
THERMAL EXPONENTIAL]
Demand interval Demand Interval 5 Minutes N/A [5 – 10 – 15 – 20– 30–60]
Trigger Enabled Trigger Enabled DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
