APPENDIX I: FACTORY DEFAULT CONFIGURATION I.1 FACTORY DEFAULT SETTINGS
GEK-106310-AF F650 DIGITAL BAY CONTROLLER i-11
Setpoint > Product Setup > time settings
Setting Description Name Default Value Step Range
User
Value
Local time zone offset Universal Coodinated
Time LOC. TIME OFFS. UTC 0 1 [-24,0 : 24,0]
To follow DST rules
DAYLIG. SAVINGS
TIME DISABLED NA [DISBLED; ENABLED]
Set the start month of the DST DST START MONTH MAR
MO
NT
H January to December
Set the start weekday of the DST DST START WEEKDAY SUNDAY
DA
Y Monday to Sunday
Set the start day instance DST START DAY INST LAST NA
First; Second; Third; Fourth;
Last
Set the starting hour of the DST DST START HOUR 2 1 [0 : 23]
Set the Stop month of the DST DST STOP MONTH OCT
Mo
nth January to December
Set the stop weekday of the DST DST STOP WEEKDAY SUNDAY
Da
y Monday to Sunday
Set the stop day instance DST STOP DAY INST LAST NA
First; Second; Third; Fourth;
Last
Set the stop hour of the DST DST STOP HOUR 2 1 [0 : 23]
IRIG-B local time IRIG-B LOCAL TIME OFF NA [ON; OFF]
Function permission IRIGB Function DISABLED NA ENABLLED; DISABLED
Stablish the sync priority PTP IRIGB Priority PTP-1588 NA PTP-1588; IRIG_B
Setpoint > System Setup > General Settings
Setting Description Name Default Value Step Range
User
Value
Phase CT ratio Phase CT Ratio 1.0 0.1 [1.0 : 6000.0]
Ground CT ratio Ground CT Ratio 1.0 0.1 [1.0 : 6000.0]
Sensitive ground CT ratio Stv Ground CT Ratio 1.0 0.1 [1.0 : 6000.0]
Phase VT ratio Phase VT Ratio 1.0 0.1 [1.0 : 6000.0]
Phase VT connection Phase VT Connection WYE N/A [WYE – DELTA]
Rated voltage Nominal Voltage 100.0 0.1 [1.0 : 250.0]
Rated Frequency Nominal Frequency 50 Hz Hz [50-60]
Phase rotation Phase Rotation ABC N/A [ABC – ACB]
Frequency reference Frequency Reference VI N/A [VI-VII-VIII]
Auxiliary Voltage Auxiliary Voltage VX N/A [VX – VN]
Snapshot Event generation Snapshot Events DISABLED N/A [DISABLED – ENABLED]
Primary meter units Primary meter units kA_kV NA A_V; kA_kV
Device name Device name NA NA NA
Setpoint > System Setup > Flex Curves
Flex Curves A > Flex Curves B > Flex Curves C > Flex Curves D
Setting Description Name Default Value Step Range
User
Value
Values for reset points 0.00 pkp Time 0.00xPKP [RST] 0.000
0.00
1 s
[0.000 : 65.535]
