GE Multilin F650 - Page 1016

I-12 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
I.1 FACTORY DEFAULT SETTINGS APPENDIX I: FACTORY DEFAULT CONFIGURATION
Values for reset points 0.05 pkp Time 0.05xPKP [RST] 0.000
0.00
1 s
[0.000 : 65.535]
… … …
0.00
1 s
[0.000 : 65.535]
Values for reset points 0.97 pkp Time 0.97xPKP [RST] 0.000
0.00
1 s
[0.000 : 65.535]
Values for reset points 0.98 pkp Time 0.98xPKP [RST] 0.000
0.00
1 s
[0.000 : 65.535]
Values for operation points 1.03 pkp Time 1.03xPKP [OP] 0.000
0.00
1 s
[0.000 : 65.535]
Values for operation points 1.05 pkp Time 1.05xPKP [OP] 0.000
0.00
1 s
[0.000 : 65.535]
… … …
0.00
1 s
[0.000 : 65.535]
Values for operation points 19.50 pkp Time 19.50xPKP [OP] 0.000
0.00
1 s
[0.000 : 65.535]
Values for operation points 20.00 pkp Time 20.00xPKP [OP] 0.000
0.00
1 s
[0.000 : 65.535]
Setpoint > System Setup > Breaker > Breaker Settings
Setting Description Name Default Value Step Range
User
Value
Number of Switchgear selected as breaker Number of Switchgear 1 1 [1 : 16]
Maximum value of KI2t Maximum KI2t 9999.99
0.01(
KA)2
s
[0.00 : 9999.99]
KI2t integration time KI2t Integ. Time 0.03 0.01s [0.03 : 0.25]
Maximum number of openings Maximum Openings 9999 1 [0 : 9999]
Maximum Openings in one hour Max.Openings 1 hour 40 1 [1 : 60]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > System Setup > Breaker > Breaker Maintenance
Setting Description Name Default Value Step Range
User
Value
KI2t Counter Phase A KI2t BKR Ph A Cnt 0.00
0.01
(KA)2
s
[0.00 : 9999.99]
KI2t Counter Phase B KI2t BKR Ph B Cnt 0.00
0.01
(KA)2
s
[0.00 : 9999.99]
KI2t Counter Phase C KI2t BKR Ph C Cnt 0.00
0.01
(KA)2
s
[0.00 : 9999.99]
Openings counter BKR Openings Cnt 0 1 [0 : 9999]
Closings counter BKR Closings Cnt 0 1 [0 : 9999]
Setpoint > System Setup > Switchgear
Setting Description Name Default Value Step Range
User
Value
Snapshot Event generation for switchgear
#1
Snapshot Events
SW
GR 1
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear
#2
Snapshot Events
SW
GR 2
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear
#3
Snapshot Events
SW
GR 3
DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear
#4
Snapshot Events
SW
GR 4
DISABLED N/A [DISABLED – ENABLED]
