GE Multilin F650 - Page 1018

I-14 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
I.1 FACTORY DEFAULT SETTINGS APPENDIX I: FACTORY DEFAULT CONFIGURATION
Input type Input PHASOR(DFT) N/A [PHASOR – RMS]
Pickup level Pickup Level 30.00
0.01
A
[0.05 : 160.00]
Trip time Trip Delay 0.00
0.01
s
[0.00 : 900.00]
Reset time Reset Delay 0.00
0.01
s
[0.00 : 900.00]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements > Phase Current > Phase Directional >
Phase Directional 1> Phase Directional 2 > Phase Directional 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Maximum Torque Angle MTA 45
1
Deg
[-90 : +90]
Operation Direction Direction FORWARD N/A [FORWARD – REVERSE]
Block logic Block Logic PERMISSION N/A [BLOCK – PERMISSION]
Polarization voltage threshold Pol V Threshold 40 1 V [0 : 300]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Voltage Memory Voltage Memory 0,00 s
0,01
s
[0,00 : 3,00]
Setpoint > Protection Elements > Phase Current > Thermal Model >
Thermal Model 1 > Thermal Model 2 > Thermal Model 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Heating constant Heat Time Constant 6.0
0.1
min
[3.0 : 600.0]
Cooling constant Cool Time Constant 2.00
0.01
time
s
He
at
Time
Ct.
[1.00 : 6.00]
Pickup level Pickup Level 1.00
0.01
A
[0.05 : 160.00]
Alarm level Alarm Level 80.0
0.10
%
[1.0 : 110.0]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements > Neutral Current > Neutral TOC
Neutral TOC 1> Neutral TOC 2 > Neutral TOC 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Pickup level Pickup Level 1.00
0.01
A
[0.05 : 160.00]
Curve shape Curve IEEE Ext Inv N/A [See list of curves]
Time Dial TD Multiplier 1.00
0.01
s
[0.00 : 900.00]
Reset type Reset INSTANTANEOUS N/A [INSTANTANEOUS – LINEAR]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
