GE Multilin F650 - Page 1020

I-16 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
I.1 FACTORY DEFAULT SETTINGS APPENDIX I: FACTORY DEFAULT CONFIGURATION
Setpoint > Protection Elements > Ground Current > Ground Directional >
Ground Directional 1 > Ground Directional 2 > Ground Directional 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Maximum Torque Angle MTA -45
1
Deg
[-90 : +90]
Operation Direction Direction FORWARD N/A [FORWARD – REVERSE]
Polarization type Polarization VO N/A
[V
0
– I
P
– V
0
+I
P
– V
0
*I
P
]
Block logic type Block Logic PERMISSION N/A [BLOCK – PERMISSION]
Polarization voltage threshold Pol V Threshold 10 1 V [0 : 300]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements > Sensitive Ground Current > Sensitive Ground TOC
Sensitive Ground TOC 1 > Sensitive Ground TOC 2 > Sensitive Ground TOC 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Input type Input PHASOR(DFT) N/A [PHASOR – RMS]
Pickup level Pickup Level 0.050
0.00
1 A
[0.005 : 16.000]
Curve shape Curve IEEE Ext Inv N/A [See list of curves]
Time Dial TD Multiplier 1.00
0.01
s
[0.00 : 900.00]
Reset type Reset INSTANTANEOUS N/A [INSTANTANEOUS – LINEAR]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements > Sensitive Ground Current > Sensitive Ground IOC
Sensitive Ground IOC 1 > Sensitive Ground IOC 2 > Sensitive Ground IOC 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Input type Input PHASOR(DFT) N/A [PHASOR – RMS]
Pickup level Pickup Level 0.100
0.00
1 A
[0.005 : 16.000]
Trip time Trip Delay 0.00
0.01
s
[0.00 : 900.00]
Reset time Reset Delay 0.00
0.01
s
[0.00 : 900.00]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements > Sensitive Ground Current > Isolated Ground IOC
Isolated Ground IOC 1 > Isolated Ground IOC 2 > Isolated Ground IOC 3
Setting Description Name Default Value Step Range
User
Value
Function Permission Function DISABLED N/A [DISABLED – ENABLED]
High Voltage level Vh Level 20 1 V [2 : 70]
Low Current level Il LEVEL 0.005
0.00
1 A
[0.005 : 0.400]
Low Voltage level Vl LEVEL 2 1 V [2 : 70]
High Current level Ih LEVEL 0.025
0.00
1 A
[0.005 : 0.400]
