APPENDIX I: FACTORY DEFAULT CONFIGURATION I.1 FACTORY DEFAULT SETTINGS
GEK-106310-AF F650 DIGITAL BAY CONTROLLER i-17
Operation time Delay 0.00
0.01
s
[0.00 : 900.00]
Deviation time to instantaneous Time to inst 0.00
0.01
s
[0.00 : 900.00]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements > Sensitive Ground Current > Sensitive Ground Directional >
Sensitive Ground Directional 1 > Sensitive Ground Directional 2 > Sensitive Ground Directional 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Maximum Torque Angle MTA -45
1
Deg
[-90 : +90]
Operation Direction Direction FORWARD N/A [FORWARD – REVERSE]
Block logic type Block Logic PERMISSION N/A [BLOCK – PERMISSION]
Polarization voltage threshold Pol V Threshold 10 1 V [0 : 300]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements > Negative Sequence Current > Negative Sequence TOC >
Negative Sequence TOC 1 > Negative Sequence TOC 2 > Negative Sequence TOC 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Pickup level Pickup Level 1.00
0.01
A
[0.05 : 160.00]
Curve shape Curve IEEE Ext Inv N/A [See list of curves]
Time Dial TD Multiplier 1.00
0.01
s
[0.00 : 900.00]
Reset type Reset INSTANTANEOUS N/A [INSTANTANEOUS – LINEAR]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements > Voltage Elements > Phase UV >
Phase UV 1 > Phase UV 2 > Phase UV 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Input mode Mode PHASE-PHASE N/A
[PHASE-PHASE, PHASE-
GR
OUND]
Pickup Level Pickup Level 10 1 V [3 : 300]
Curve shape Curve DEFINITE TIME N/A
[DEFINITE TIME – INVERSE
TIME]
Time Dial Delay 10.00
0.01
s
[0.00 : 900.00]
Minimum Voltage Threshold Minimum Voltage 5 1 V [0 : 300]
Operation logic Logic ANY PHASE N/A
[ANY PHASE – TWO PHASES
– ALL PHASES]
Supervision by breaker status Supervised by 52 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements > Voltage Elements > Phase OV >
Phase OV 1 > Phase OV 2 > Phase OV 3
Setting Description Name Default Value Step Range
User
Value
