I-18 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
I.1 FACTORY DEFAULT SETTINGS APPENDIX I: FACTORY DEFAULT CONFIGURATION
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Pickup Level Pickup Level 10 1 V [3 : 300]
Trip time Trip Delay 10.00
0.01
s
[0.00 : 900.00]
Reset time Reset Delay 0.00
0.01
s
[0.00 : 900.00]
Operation logic Logic ANY PHASE N/A
[ANY PHASE – TWO PHASES
– ALL PHASES]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements > Voltage Elements >
>Neutral OV High > Neutral OV High 1 > Neutral OV High 2 > Neutral OV High 3
>Neutral OV Low > Neutral OV Low 1 > Neutral OV Low 2 > Neutral OV Low 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Pickup Level Pickup Level 10 1 V [3 : 300]
Trip time Trip Delay 10.00
0.01
s
[0.00 : 900.00]
Reset time Reset Delay 0.00
0.01
s
[0.00 : 900.00]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements > voltage elements > Negative Sequence OV >
Negative Sequence OV 1 > Negative Sequence OV 2 > Negative Sequence OV 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Pickup Level Pickup Level 10 1 V [3 : 300]
Trip time Trip Delay 10.00
0.01
s
[0.00 : 900.00]
Reset time Reset Delay 0.00
0.01
s
[0.00 : 900.00]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements >voltage elements > Auxiliary oV
Auxiliary oV 1 > Auxiliary oV 2 > Auxiliary oV 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Pickup Level Pickup Level 10 1 V [3 : 300]
Trip Time Trip Delay 10.00
0.01
s
[0.00 : 900.00]]
Reset Time Reset Delay 0.00
0.01
s
[0.00 : 900.00]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements >voltage elements > Auxiliary UV
Auxiliary UV 1 > Auxiliary UV 2 > Auxiliary UV 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Pickup Level Pickup Level 10 1 V [3 : 300]
