APPENDIX I: FACTORY DEFAULT CONFIGURATION I.1 FACTORY DEFAULT SETTINGS
GEK-106310-AF F650 DIGITAL BAY CONTROLLER i-19
Curve shape Curve DEFINITE TIME N/A
[DEFINITE TIME – INVERSE
TIME]
Time Dial Delay 10.00
0.01
s
[0.00 : 900.00]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements > Power > Forward Power
Forward Power 1 > Forward Power 2 > Forward Power 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Block from offline Blk Time After Close 0.00
0.01
s
[0.00 : 900.00]
Pickup level for stage 1 Stage 1 Tap 10.00
0.01
MW
[0.00 : 10000.00]
Trip time for stage 1 Stage 1 Time 60.00
0.01
s
[0.00 : 900.00]
Pickup level for stage 2 Stage 2 Tap 20.00
0.01
MW
[0.00 : 10000.00]
Trip time for stage 2 Stage 2 Time 60.00
0.01
s
[0.00 : 900.00]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements > Power > Directional Power>
Directional Power 1 > Directional Power 2 > Directional Power 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Block from offline Blk Time After Close 0.00
0.01
s
[0.00 : 900.00]
Directional Angle for stage 1 Dir Power Angle 1 0.00
0.01
Deg
[0.00 : 359.99]
Pickup level for stage 1 Stage 1 Tap 10.00
0.01
MW
[-10000.00 : 10000.00]
Trip time for stage 1 Stage 1 Time 60.00
0.01
s
[0.00 : 900.00]
Directional Angle for stage 2 Dir Power Angle 2 0.00
1
Deg
[0.00 : 359.99]
Pickup level for stage 2 Stage 2 Tap 20.00
0.01
MW
[-10000.00 : 10000.00]
Trip time for stage 2 Stage 2 Time 60.00
0.01
s
[0.00 : 900.00]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Protection Elements > Power
WATT GND FLT HIGH 1 > WATT GND FLT HIGH 2 > WATT GND FLT HIGH 3
WATT GND FLT LOW 1 > WATT GND FLT LOW 2 > WATT GND FLT LOW 3
SETTING DESCRIPTION NAME DEFAULT VALUE STEP RANGE
USER
VALUE
Function permission Function DISABLED N/A [DISABLED-ENABLED]
Supervision minimum voltage Voltage Pickup Level 2 0.01
V
[2.00 : 70.00]
Source of operating current. Current selection IN N/A [IN-IG]
Pickup Level for Overcurrent OC Pickup Level 0,005 0.00
1A
[0.005 : 0.400]
