GE Multilin F650 - Page 1024

I-20 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
I.1 FACTORY DEFAULT SETTINGS APPENDIX I: FACTORY DEFAULT CONFIGURATION
Pickup Delay for Overcurrent OC Pickup Delay 0,2 0.01
s
[0.00 : 600.00]
Pickup Level for operating Power Power Pickup 0,01 0.01
W
[0.01 : 4.50]
Max torque angle MTA 0 1
Deg
[0 : 360]
Pickup Delay for Operating Power Power Pickup Delay 0,2 0.01
s
[0.00 : 600.00]
Curve shape Curve DEFINITE TIME N/A [DEFINITE TIME - INVERSE
TIME - USER C
URVE A -
USER CURVE B - USER
CURVE C - USER CURVE D]
Multiplier Multiplier 1 0.01
s
[0.02 : 2.00]
Snapshot event generation Snapshot Event DISABLED N/A [DISABLED-ENABLED]
Setpoint > Control Elements > Setting Group
Setting Description Name Default Value Step Range
User
Value
Setting Grouping Permission Function DISABLED N/A [DISABLED – ENABLED]
Active Group Active Group GROUP 1 N/A
[GROUP 1 – GROUP 2 –
GR
OUP 3]
Snapshot Event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Control Elements > Underfrequency
Underfrequency 1 > Underfrequency 2 > Underfrequency 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Pickup level Pickup Level 49.50
0.01
Hz
[20.00 : 65.00]
Trip time Trip Delay 0.00
0.01
s
[0.00 : 900.00]
Reset time Reset Delay 0.00
0.01
s
[0.00 : 900.00]
Minimum voltage threshold Minimum Voltage 30 1 V [10 : 300]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Control Elements > Overfrequency
Overfrequency 1 > Overfrequency 2 > Overfrequency 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Pickup level Pickup Level 50.50
0.01
Hz
[20.00 : 65.00]
Trip time Trip Delay 0.00
0.01
s
[0.00 : 900.00]
Reset time Reset Delay 0.00
0.01
s
[0.00 : 900.00]
Minimum voltage threshold Minimum Voltage 30 1 V [10 : 300]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
