APPENDIX I: FACTORY DEFAULT CONFIGURATION I.1 FACTORY DEFAULT SETTINGS
GEK-106310-AF F650 DIGITAL BAY CONTROLLER i-21
Setpoint > Control Elements > Synchrocheck
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Dead bus voltage level Dead Bus Level 10.00
0.01
V
[0.00 : 300.00]
Live bus voltage level Live Bus Level 50.00
0.01
V
[0.00 : 300.00]
Dead line voltage level Dead Line Level 10.00
0.01
V
[0.00 : 300.00]
Live line voltage level Live Line Level 50.00
0.01
V
[0.00 : 300.00]
Voltage Difference Max Volt Difference 10.00
0.01
V
[2.00 : 300.00]
Angle Difference Max Angle Difference 10.0
0.1
Deg
[2.0 : 80.0]
Frequency Slip Max Freq Difference 20
10
mH
z
[10 : 5000]
Breaker Closing time Time 0.50
0.01
s
[0.01 : 600.00]
Dead Line – Dead Bus Function permission DL-DB Function DISABLED N/A [DISABLED – ENABLED]
Live Line – Dead Bus Function permission LL-DB Function DISABLED N/A [DISABLED – ENABLED]
Dead Line – Live Bus Function permission DL-LB Function DISABLED N/A [DISABLED – ENABLED]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Control Elements > Autoreclose
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Maximum Number of shots Max Number Shots 1 N/A [1 : 4]
Dead time 1 Dead Time 1 0.00
0.01
s
[0.00 : 900.00]
Dead time 2 Dead Time 2 0.00
0.01
s
[0.00 : 900.00]
Dead time 3 Dead Time 3 0.00
0.01
s
[0.00 : 900.00]
Dead time 4 Dead Time 4 0.00
0.01
s
[0.00 : 900.00]
Reclaim time or reset lockout delay Reclaim Time 0.00
0.01
s
[0.00 : 900.00]
Reclose conditions permission Cond. Permission DISABLED N/A [DISABLED – ENABLED]
Hold time Hold Time 0.00
0.01
s
[0.00 : 900.00]
Reset time Reset Time 0.00
0.01
s
[0.00 : 900.00]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Control Elements > breaker failure
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Supervision (retrip) pickup level Supervision Pickup 1.00
0.01
A
[0.05 : 160.00]
Hiset pickup level Hiset Pickup 5.00
0.01
A
[0.05 : 160.00]
