I-22 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
I.1 FACTORY DEFAULT SETTINGS APPENDIX I: FACTORY DEFAULT CONFIGURATION
Lowset pickup level Lowset Pickup 2.00
0.01
A
[0.05 : 160.00]
Internal arc pickup level Internal Arc Pickup 0.10
0.01
A
[0.05 : 160.00]
Internal arc time delay Internal Arc Delay 10.00
0.01
s
[0.00 : 900.00]
Retrip time delay Supervision Delay 10.00
0.01
s
[0.00 : 900.00]
Hiset time delay HiSet Delay 10.00
0.01
s
[0.00 : 900.00]
Lowset time delay LowSet Delay 10.00
0.01
s
[0.00 : 900.00]
Second stage time delay 2nd Step Delay 10.00
0.01
s
[0.00 : 900.00]
WITHOUT current element time delay No Current Delay 10.00
0.01
s
[0.00 : 900.00]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Control Elements > VT Fuse Failure)
Setting Description Name Default Value Step Range
User
Value
Function permission Function
DISABLED
N/A [DISABLED – ENABLED]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Setpoint > Control Elements > BROKEN CONDUCTOR
Broken Conductor 1 > Broken Conductor 2 > Broken Conductor 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Tap Level in percentage of I2/I1 Tap 20
0.10
%
[20.0 : 100.0]
Trip Time Trip Delay 60
0.01
s
[0.00 : 900.00]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
Current Inhibition Level setting Operation Threshold 0.005
0.00
1 A
[0.000 : 1.000]
Setpoint > Control Elements > Locked Rotor
Locked Rotor 1 > Locked Rotor 2 > Locked Rotor 3
Setting Description Name Default Value Step Range
User
Value
Function permission Function DISABLED N/A [DISABLED – ENABLED]
Input type Input PHASOR(DFT) N/A [PHASOR – RMS]
Full load current Full Load Current 0.50 KA [0.10 : 10.00]
Pickup level Pickup Level 1.01 N/A [1.01 : 109.00]
Trip time Trip Delay 0.00 s [0.00 : 900.00]
Reset time Reset Delay 0.00 s [0.00 : 900.00]
Snapshot event generation Snapshot Events ENABLED N/A [DISABLED – ENABLED]
SETPOINT > CONTROL ELEMENTS > PULSE COUNTERS
SETTING DESCRIPTION NAME DEFAULT VALUE STEP RANGE
USER
VALUE
Pulse counter enabling setting CntPulses Enabled X DISABLED N/A [DISABLED – ENABLED]
Name of the pulse counter CntPulses Name X Pulse Counter 1 N/A N/A
