I-32 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
I.2 FACTORY DEFAULT CONFIGURATION APPENDIX I: FACTORY DEFAULT CONFIGURATION
PH TOC3 HIGH C BLK
GROUP 3 BLOCKED
CONT IP_F_CC3 (51P BLOCK)(CC3)
PHASE DIR3 C OP NOT
LATCHED VIRT IP 5
NEUTRAL TOC1 BLOCK
GROUP 1 BLOCKED
NEUTRAL DIR1 OP NOT
NEUTRAL TOC2 BLOCK
GROUP 2 BLOCKED
NEUTRAL DIR2 OP NOT
NEUTRAL TOC3 BLOCK
GROUP 3 BLOCKED
NEUTRAL DIR3 OP NOT
GROUND TOC1 BLOCK
GROUP 1 BLOCKED
CONT IP_F_CC6 (51G BLOCK)(CC6)
GROUND DIR1 OP NOT
LATCHED VIRT IP 7
GROUND TOC2 BLOCK
GROUP 2 BLOCKED
CONT IP_F_CC6 (51G BLOCK)(CC6)
GROUND DIR2 OP NOT
LATCHED VIRT IP 7
GROUND TOC3 BLOCK
GROUP 3 BLOCKED
CONT IP_F_CC6 (51G BLOCK)(CC6)
GROUND DIR3 OP NOT
LATCHED VIRT IP 7
SENS GND TOC1 BLOCK
GROUP 1 BLOCKED
SENS GND DIR1 OP NOT
LATCHED VIRT IP 8
SENS GND TOC2 BLOCK
GROUP 2 BLOCKED
SENS GND DIR2 OP NOT
LATCHED VIRT IP 8
SENS GND TOC3 BLOCK
GROUP 3 BLOCKED
SENS GND DIR3 OP NOT
LATCHED VIRT IP 8
PHASE UV1 BLOCK GROUP 1 BLOCKED
PHASE UV2 BLOCK GROUP 2 BLOCKED
PHASE UV3 BLOCK GROUP 3 BLOCKED
NEG SEQ OV1 BLOCK GROUP 1 BLOCKED
NEG SEQ OV2 BLOCK GROUP 2 BLOCKED
NEG SEQ OV3 BLOCK GROUP 3 BLOCKED
THERMAL1 BLOCK GROUP 1 BLOCKED
THERMAL2 BLOCK GROUP 2 BLOCKED
THERMAL3 BLOCK GROUP 3 BLOCKED
PHASE DIR1 BLK INP
GROUP 1 BLOCKED
CONT IP_F_CC4 (67P BLOCK)(CC4)
LATCHED VIRT IP 9
PHASE DIR2 BLK INP
GROUP 2 BLOCKED
CONT IP_F_CC4 (67P BLOCK)(CC4)
LATCHED VIRT IP 9
SETPOINT > RELAY CONFIGURATION > PROTECTION ELEMENTS
PROTECTION ELeMENT SOURCE SIGNAL LOGIC SOURCE LOGIC
