APPENDIX I: FACTORY DEFAULT CONFIGURATION I.2 FACTORY DEFAULT CONFIGURATION
GEK-106310-AF F650 DIGITAL BAY CONTROLLER i-33
PHASE DIR3 BLK INP
GROUP 3 BLOCKED
CONT IP_F_CC4 (67P BLOCK)(CC4)
LATCHED VIRT IP 9
NEUTRAL DIR1 BLK INP GROUP 1 BLOCKED
NEUTRAL DIR2 BLK INP GROUP 2 BLOCKED
NEUTRAL DIR3 BLK INP GROUP 3 BLOCKED
GROUND DIR1 BLK INP
GROUP 1 BLOCKED
LATCHED VIRT IP 10
GROUND DIR2 BLK INP
GROUP 2 BLOCKED
LATCHED VIRT IP 10
GROUND DIR3 BLK INP
GROUP 3 BLOCKED
LATCHED VIRT IP 10
NEUTRAL OV1 HIGH BLK
GROUP 1 BLOCKED
LATCHED VIRT IP 12
NEUTRAL OV2 HIGH BLK
GROUP 2 BLOCKED
LATCHED VIRT IP 12
NEUTRAL OV3 HIGH BLK
GROUP 3 BLOCKED
LATCHED VIRT IP 12
NEUTRAL OV1 LOW BLK GROUP 1 BLOCKED
NEUTRAL OV2 LOW BLK GROUP 2 BLOCKED
NEUTRAL OV3 LOW BLK GROUP 3 BLOCKED
AUXILIARY UV1 BLOCK GROUP 1 BLOCKED
AUXILIARY UV2 BLOCK GROUP 2 BLOCKED
AUXILIARY UV3 BLOCK GROUP 3 BLOCKED
PHASE OV1 BLOCK
GROUP 1 BLOCKED
LATCHED VIRT IP 11
PHASE OV2 BLOCK
GROUP 2 BLOCKED
LATCHED VIRT IP 11
PHASE OV3 BLOCK
GROUP 3 BLOCKED
LATCHED VIRT IP 11
AUXILIARY OV1 BLOCK GROUP 1 BLOCKED
AUXILIARY OV2 BLOCK GROUP 2 BLOCKED
AUXILIARY OV3 BLOCK GROUP 3 BLOCKED
NEG SEQ TOC1 BLOCK GROUP 1 BLOCKED
NEG SEQ TOC2 BLOCK GROUP 2 BLOCKED
NEG SEQ TOC3 BLOCK GROUP 3 BLOCKED
OVERFREQ1 BLOCK GROUP 1 BLOCKED
OVERFREQ2 BLOCK GROUP 2 BLOCKED
OVERFREQ3 BLOCK GROUP 3 BLOCKED
UNDERFREQ1 BLOCK GROUP 1 BLOCKED
UNDERFREQ2 BLOCK GROUP 2 BLOCKED
UNDERFREQ3 BLOCK GROUP 3 BLOCKED
SETT GROUPS BLOCK Not Configured
BROKEN CONDUCT1 BLK GROUP 1 BLOCKED
BROKEN CONDUCT2 BLK GROUP 2 BLOCKED
BROKEN CONDUCT3 BLK GROUP 3 BLOCKED
ISOLATED GND1 BLK
GROUP 1 BLOCKED
SENS GND DIR1 OP NOT
SETPOINT > RELAY CONFIGURATION > PROTECTION ELEMENTS
PROTECTION ELeMENT SOURCE SIGNAL LOGIC SOURCE LOGIC
