APPENDIX I: FACTORY DEFAULT CONFIGURATION I.2 FACTORY DEFAULT CONFIGURATION
GEK-106310-AF F650 DIGITAL BAY CONTROLLER i-35
DIR PWR3 BLOCK GROUP 3 BLOCKED
LOCKED ROTOR1 BLK GROUP 1 BLOCKED
LOCKED ROTOR2 BLK GROUP 2 BLOCKED
LOCKED ROTOR3 BLK GROUP 3 BLOCKED
FREQ RATE1 BLOCK GROUP 1 BLOCKED
FREQ RATE2 BLOCK GROUP 2 BLOCKED
FREQ RATE3 BLOCK GROUP 3 BLOCKED
LOAD ENCR1 BLOCK GROUP 1 BLOCKED
LOAD ENCR2 BLOCK GROUP 2 BLOCKED
LOAD ENCR3 BLOCK GROUP 3 BLOCKED
32N1 HIGH BLOCK GROUP 1 BLOCKED
32N2 HIGH BLOCK GROUP 2 BLOCKED
32N3 HIGH BLOCK GROUP 3 BLOCKED
32N1 LOW BLOCK GROUP 1 BLOCKED
32N2 LOW BLOCK GROUP 2 BLOCKED
32N3 LOW BLOCK GROUP 3 BLOCKED
THERMAL1 A RST OPERATION BIT 4
THERMAL1 B RST OPERATION BIT 4
THERMAL1 C RST OPERATION BIT 4
THERMAL2 A RST OPERATION BIT 4
THERMAL2 B RST OPERATION BIT 4
THERMAL2 C RST OPERATION BIT 4
THERMAL3 A RST OPERATION BIT 4
THERMAL3 B RST OPERATION BIT 4
THERMAL3 C RST OPERATION BIT 4
Synchrocheck BLK INP Not Configured
AR LEVEL BLOCK
CONT IP_F_CC8 (79 BLOCK)(CC8)
LATCHED VIRT IP 14
AR PULSE BLOCK Not Configured
AR PULSE UNBLOCK Not Configured
AR INITIATE
VO_083_GENERAL_TRIP
CONT IP_F_CC7 (79 INITIATE)(CC7)
LATCHED VIRT IP 13
AR CONDS INPUT
SYNCHK CLOSE PERM NOT
NOT
LATCHED VIRT IP 15
BKR FAIL INITIATE Not Configured
GROUP 1 ACT ON Not Configured
GROUP 2 ACT ON Not Configured
GROUP 3 ACT ON Not Configured
FAULT REPORT TRIGG VO_083_GENERAL_TRIP
CLEAR FAULT REPORTS Not Configured
DEMAND TRIGGER INP Not Configured
DEMAND RESET INP OPERATION BIT 7
FREEZE ENERGY CNT Not Configured
UNFREEZE ENERGY CNT Not Configured
RESET ENERGY CNT OPERATION BIT 6
RESET KI2t COUNTERS OPERATION BIT 5
RESET BKR COUNTERS OPERATION BIT 5
SETPOINT > RELAY CONFIGURATION > PROTECTION ELEMENTS
PROTECTION ELeMENT SOURCE SIGNAL LOGIC SOURCE LOGIC
To Next Page
