I-36 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
I.2 FACTORY DEFAULT CONFIGURATION APPENDIX I: FACTORY DEFAULT CONFIGURATION
SETPOINT > RELAY CONFIGURATION > OSCILLOGRAPHY
DIGITAL CHANNEL NAME SOURCE SIGNAL LOGIC SOURCE LOGIC
DIG_CHANNEL#1 TRIP VO_083_GENERAL_TRIP
DIG_CHANNEL#2 50/51P TRIP VO_019_PHASE_OVERCURRENT_TRIP
DIG_CHANNEL#3 50/51G TRIP VO_069_GROUND_OVERCURRENT_TRIP
DIG_CHANNEL#4 27 TRIP VO_073_27P_TRIP
DIG_CHANNEL#5 59 TRIP VO_074_59P_TRIP
DIG_CHANNEL#6 PICKUP VO_085_GENERAL_PKP
DIG_CHANNEL#7 50/51P PICKUP VO_007_PHASE_OVERCURRENT_PKP
DIG_CHANNEL#8 50/51G PICKUP VO_009_GROUND_OVERCURRENT_PKP
DIG_CHANNEL#9 27 PICKUP VO_045_27P_PKP
DIG_CHANNEL#10 59 PICKUP VO_046_59P_PKP
DIG_CHANNEL#11 79 READY AR READY
DIG_CHANNEL#12 79 IN-PROG AR RCL IN PROGRESS
DIG_CHANNEL#13 79 BLOCK AR BLOCK
DIG_CHANNEL#14 79 INHIBIT AR CONDS INPUT NOT
DIG_CHANNEL#15 79 LOCKOUT AR LOCKOUT
DIG_CHANNEL#16 Not Configured
OSCILLO TRIGGER OSCILLO TRIGGER
OPERATION BIT 8
VO_083_GENERAL_TRIP
SETPOINT > RELAY CONFIGURATION > OPERATIONS
OPERATION OPERATION TEXT SETTINGS VALUE/SOURCE
Operation1 CLOSE BREAKER
INTERLOCK(LOGIC) SYNCHK CLOSE PERM
FINAL STATES AND LOGIC BREAKER CLOSED
FRONT KEY I Key
INPUT Not configured
VIRTUAL OUTPUT Not configured
TIMEOUT 1000
CHANNELS ALL
Operation2 OPEN BREAKER
INTERLOCK(LOGIC) Not configured
FINAL STATES AND(LOGIC) BREAKER OPEN
FRONT KEY O Key
INPUT Not configured
VIRTUAL OUTPUT Not configured
TIMEOUT 1000
CHANNELS ALL
Operation3 LEDS RESET
INTERLOCK(LOGIC) Not configured
FINAL STATES AND(LOGIC) Not configured
FRONT KEY Not configured
INPUT Not configured
VIRTUAL OUTPUT Not configured
TIMEOUT 500
CHANNELS ALL
SETPOINT > RELAY CONFIGURATION > PROTECTION ELEMENTS
PROTECTION ELeMENT SOURCE SIGNAL LOGIC SOURCE LOGIC
