APPENDIX I: FACTORY DEFAULT CONFIGURATION I.2 FACTORY DEFAULT CONFIGURATION
GEK-106310-AF F650 DIGITAL BAY CONTROLLER i-37
Operation4 THERMAL RESET
INTERLOCK(LOGIC) Not configured
FINAL STATES AND(LOGIC) Not configured
FRONT KEY Not configured
INPUT Not configured
VIRTUAL OUTPUT Not configured
TIMEOUT 500
CHANNELS ALL
Operation5 BRK COUNTERS RESET
INTERLOCK(LOGIC) Not configured
FINAL STATES AND(LOGIC) Not configured
FRONT KEY Not configured
INPUT Not configured
VIRTUAL OUTPUT Not configured
TIMEOUT 500
CHANNELS ALL
Operation6 ENERGY RESET
INTERLOCK(LOGIC) Not configured
FINAL STATES AND(LOGIC) Not configured
FRONT KEY Not configured
INPUT Not configured
VIRTUAL OUTPUT Not configured
TIMEOUT
500
CHANNELS ALL
Operation7 DEMAND RESET
INTERLOCK(LOGIC) Not configured
FINAL STATES AND(LOGIC) Not configured
FRONT KEY Not configured
INPUT Not configured
VIRTUAL OUTPUT Not configured
TIMEOUT 500
CHANNELS ALL
Operation8 TRIGGER OSCILLO
INTERLOCK(LOGIC) Not configured
FINAL STATES AND(LOGIC) Not configured
FRONT KEY Not configured
INPUT Not configured
VIRTUAL OUTPUT Not configured
TIMEOUT 500
CHANNELS ALL
Operation9 Not configured
INTERLOCK(LOGIC) Not configured
FINAL STATES AND(LOGIC) Not configured
FRONT KEY Not configured
INPUT Not configured
VIRTUAL OUTPUT Not configured
TIMEOUT Not configured
CHANNELS
Not configured
SETPOINT > RELAY CONFIGURATION > OPERATIONS
OPERATION OPERATION TEXT SETTINGS VALUE/SOURCE
