CHAPTER 4: INTERFACES, SETTINGS & ACTUAL VALUES 4.2 HUMAN-MACHINE INTERFACE (HMI)
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 4-49
Table 4-13: Protection Element and control element menu for firmware version 7.50 or above
MAIN SETTINGS MENU FIRST LEVEL SECOND LEVEL THIRD LEVEL MAIN SETTINGS MENU
Protection Element >
Setting Group X>
Phase Current >
Phase TOC High > Phase TOC High 1..3
Phase TOC Low > Phase TOC Low 1..3
Phase IOC High > Phase IOC High 1..3
Phase IOC Low > Phase IOC Low 1..3
Phase Directional > Phase Directional 1..3
Thermal Model > Thermal Model 1..3
Neutral Current >
Neutral TOC > Neutral TOC 1..3
Neutral IOC > Neutral IOC 1..3
Neutral Dir > Neutral Dir 1..3
Ground Current >
Ground TOC > Ground TOC 1..3
Ground IOC > Ground IOC 1..3
Ground Dir > Ground Dir 1..3
Sens. Ground Curr >
Sens. Ground TOC > Sens. Ground TOC 1..3
Sens. Ground IOC > Sens. Ground IOC 1..3
Isolated Gnd IOC > Isolated Gnd IOC 1..3
Sens. Ground Dir. > Sens. Ground Dir. 1..3
Neg. Seq. Current >
Neg. Seq. TOC > Neg. Seq. TOC 1..3
Voltage Elements >
Phase UV > Phase UV 1..3
Phase OV > Phase OV 1
Neutral OV High > Neutral OV High 1..3
Neutral OV Low > Neutral OV Low 1
Neg. Seq. OV > Neg. Seq. OV 1..3
Auxiliary OV > Auxiliary OV 1..3
Auxiliary UV > Auxiliary UV 1
Power >
Forward Power > Forward Power 1..3
Directional Power > Directional Power 1..3
Watt Gnd Flt High > Watt Gnd Flt High 1
Watt Gnd Flt Low > Watt Gnd Flt Low 1..3
Frequency >
Underfrequency > Underfrequency 1..6
To Next Page
