CHAPTER 5: SETPOINTS 5.9 RELAY CONFIGURATION
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 5-173
Breaker+Extraction device (Vertical) Only for N model (IEC selection)
Breaker+Extraction device (Horizontal) Only for N model (IEC selection)
Isolator Only for N model (IEC selection)
Isolator Remote controlled Only for N model (IEC selection)
Neutral Reactance Only for N model (IEC selection)
“Encravado” Interlocked Only for N model (IEC selection)
Autorecloser In Service/ Out of Service Only for N model (IEC selection)
“M”/”A” Symbol for Manual/Automatic Only for N model (IEC selection)
“Regime Especial Exploração” Only for N model (IEC selection)
Voltage transformer Only for N model (IEC selection)
Different Text properties (Bold/Vertical/Reverse
Video)
Only for N model (IEC selection)
To Next Page
