CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-15
S15 DeleteDataSet TP - N
S16 Ge t Da t a S e t D i r ec t o ry TP - Y
Substitution (Clause 12)
S17 SetDataValues TP - N
Setting group control (Clause 13)
S18 SelectActiveSG TP - Y
S19 SelectEditSG TP - Y
S20 SetSGValues TP - Y
S21 ConfirmEditSGValues TP - Y
S22 Ge t SG Va l ue s TP - Y
S23 Ge t SG C BV a lu e s TP - Y
Reporting (Clause 14)
Buffered report control block (BRCB)
S24 Report TP - Y
S24-1 data-change (dchg) - Y
S24-2 qchg-change (qchg) - N
S24-3 data-update (dupd) - N
S25 Ge t BRC B Va l ue s TP - Y
S26 SetBRCBValues TP - Y
Unbuffered report control block (URCB)
S27 Report TP - Y
S27-1 data-change (dchg) - Y
S27-2 qchg-change (qchg) - N
S27-3 data-update (dupd) - N
S28 Ge t URC B V a l ue s TP - Y
S29 SetURCBValues TP - Y
Logging (Clause 14)
Log control block
S30 Ge t L C B V a l u e s TP - N
S31 SetLCBValues TP - N
Log
S32 QueryLogByTime TP - N
S33 QueryLogAfter TP - N
S34 GetLogStatusValues TP - N
Generic substation event model (GSE) (Clause 14.3.5.3.4)
GOOSE-CONTROL-BLOCK
S35 SendGOOSEMessage MC - Y
S36 GetGoReference TP - N
S37 GetGOOSEElementNumber TP - N
S38 Ge t Go C BV a lu e s TP - Y
S39 SetGoCBValues TP - Y
Only GoEna is
writable, the rest
of attributes are
read-only
GSSE-CONTROL-BLOCK
S40 SendGSSEMessage MC - Y
