7-16 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2 PICS (“Protocol Implementation Conformance Statement”)
The tables in sections below appear in the same sequence as in standard IEC 61850-8-1, section 24.
The tables refer to part 7 of the standard and the correspon
ding information must be contained in the PICS.
S41 GetGsReference TP - N
S42 GetGSSEElementNumber TP - N
S43 Ge t GsC B Va l ue s TP - Y
S44 SetGsCBValues TP - Y
Transmission of sampled value model (SVC) (Clause 16)
Multicast SVC
S45 SendMSVMessage MC - N
S46 GetMSVCBValues TP - N
S47 SetMSVCBValues TP - N
Unicast SVC
S48 SendUSVMessage TP - N
S49 GetUSVCBValues TP - N
S50 SetUSVCBValues TP - N
Control (Clause 17.5.1)
S51 Select - Y
S52 SelectWithValue TP - Y
S53 Cancel TP - Y
S54 Operate TP - Y
S55 Command- Termination TP - Y
S56 TimeActivated-Operate TP - N
File transfer (Clause 20)
S57 Ge t Fi l e TP - Y
S58 SetFile TP - N
S59 DeleteFile TP - N
S60 GetFileAttributeValues TP - Y
Time (Clause 5.5)
T1 Time resolution of internal clock 10 Nearest negative
p
ower of 2 in
seconds
T2 Time accuracy of internal clock T0
T1
Y T2
T3
T4
T5
T3 Supported TimeStamp resolution 10 Nearest value of
2*
*-n in seconds
according to
5.5.3.7.3.3 of Part
7-2
