CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-39
S24-2 1,2 quality-change (qchg) Y
S24-3 1,2 data-update (dupd) N
S25 1,2 GetBRCBValues TP Y
S26 1,2 SetBRCBValues TP Y
Unbuffered report control block (URCB)
S27 1,2 Report TP Y
S27-1 1,2 data-change (dchg) Y
S27-2 1,2 quality-change (qchg) Y
S27-3 1,2 data-update (dupd) N
S28 1,2 GetURCBValues TP Y
S29 1,2 SetURCBValues TP Y
Logging
Log control
S30 1,2 GetLCBValues TP N
S31 1,2 SetLCBValues TP N
Log
S32 1,2 QueryLogByTime TP N
S33 1,2 QueryLogAfter TP N
S34 1,2 GetLogStatusValues TP N
Generic substation event model (GSE)
GOOSE
S35 1,2 SendGOOSEMessage MC Y
GOOSE Control Block
S36 1,2 GetGoReference TP
S37 1,2 GetGOOSEElementNumber TP
S38 1,2 GetGoCBValues TP Y
S39 1,2 SetGoCBValues TP Y
GSSE (Ed2:61850-7-2 Annex C)
S40 1,2 SendGSSEMessage MC N Deprecated
GSSE Control Block (Ed2:61850-7-2 Annex C)
S41 1,2 GetGsReference TP N Deprecated
S42 1,2 GetGSSEDataOffset TP N Deprecated
S43 1,2 GetGsCBValues TP N Deprecated
S44 1,2 SetGsCBValues TP N Deprecated
Transmission of sampled value model (SVC)
Multicast SV
S45 1,2 SendMSVMessage MC N Use for 9-2LE or IEC 61869-9
Multicast Sampled Value Control Block
S46 1,2 GetMSVCBValues TP N
S47 1,2 SetMSVCBValues TP N
Unicast SV
S48 1,2 SendUSVMessage TP N
Unicast Sampled Value Control Block
S49 1,2 GetUSVCBValues TP N
S50 1,2 SetUSVCBValues TP N
Control
S51 1,2 Select TP Y SBO Normal Security
S52 1,2 SelectWithValue TP Y SBO Enhanced Security
S53 1,2 Cancel TP Y
S54 1,2 Operate TP Y
S55 1,2 CommandTermination TP Y
S56 1,2 TimeActivatedOperate TP N
