7-38 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
4 ACSI service conformance statement
The ACSI service conformance statement is defined in Table 7-7: ACSI service conformance statement.
Table 7-7: ACSI service conformance statement
For all IEDs
M16 Time Y Y
Y = service is supported
N or empty = service is not supported
Ed ACSI Service
AA:
TP/MC
Client
Sub(C)
Server
Pub(S)
Comments
Server
S1 1,2
GetServerDirectory(LOGICAL-
DEVICE)
TP Y
Application association
S2 1,2 Associate TP Y
S3 1,2 Abort TP Y
S4 1,2 Release TP Y
Logical device
S5 1,2 GetLogicalDeviceDirectory TP Y
Logical node
S6 1,2 GetLogicalNodeDirectory TP Y
S7 1,2 GetAllDataValues TP Y
Data
S8 1,2 GetDataValues TP Y
S9 1,2 SetDataValues TP Y
S10 1,2 GetDataDirectory TP Y
S11 1,2 GetDataDefinition TP Y
Data set
S12 1,2 GetDataSetValues TP Y
S13 1,2 SetDataSetValues TP N
S14 1,2 CreateDataSet TP N
S15 1,2 DeleteDataSet TP N
S16 1,2 GetDataSetDirectory TP Y
Substitution
S17 1 SetDataValues TP N Ed1 only
Setting group control
S18 1,2 SelectActiveSG TP Y
S19 1,2 SelectEditSG TP Y
S20 1,2 SetEditSGValues TP Y
S21 1,2 ConfirmEditSGValues TP Y
S22 1,2 GetEditSGValues TP Y
S23 1,2 GetSGCBValues TP Y
Reporting
Buffered report control block (BRCB)
S24 1,2 Report TP Y
S24-1 1,2 data-change (dchg) Y
