7-52 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
Note: ACT includes origin attribute in ST, this is implemented according to Tissue 68.
2.3.1.4 hseRDIR
This logical node class is used for sensitive ground directional elements and has 3 instances inside the device.
Note: ACT includes origin attribute in ST, this is implemented according to Tissue 68.
2.3.2 RREC (Autoreclosing)
This logical node class is used for autorecloser and has 1 instance inside the device.
BlkValV ASG Minimun operating current O (0, 300) Pol V Threshold
PolOpMod ING Direction E (Reverse, Forward)
BlkMod ING Block Logical E (Prmission, Blocked)
RDIREna SPG Function Permission E (Enable, Disable)
PolQty ING Polarisation O (VO,IP,VO+IP,VO*IP)
RDIR class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
RDIR Directional Element
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
NamPlt LPL Name plate M
Status Information
Dir ACD Direction M
Fixed to unknown value
Op ACT Operate E Sens Gnd Dir OP
Blk ACT Block E Sens Gnd Dir Block
BlkIn ACT Sens Gnd Dir Blk Inp E Sens Gnd Dir Blk Inp
Settings
ChrAng ASG Characteristic Angle O (-90, 90) MTA
BlkValV ASG Minimun operating current O
(0, 300) Pol V Threshold
PolOpMod ING Direction E (Reverse, Forward)
BlkMod ING Block Logical E (Prmission, Blocked)
RDIREna SPG Function Permission E (Enable, Disable)
RREC class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
RREC Autoreclosing
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
Status Information
Op ACT Operate M AR Close Breaker
AutoRecSt INS Auto Reclosing status M
AR Status
AutoRecLo INS Auto Reclosing Lockout Status E AR Lockout Mode
