Notes:
AutoRecSt object includes extra enum values specified by Tissue 3 and Tissue 133 (See the Enum types implementation
section).
ACT includes origin attribute in ST, this is implemented according to Tissue 68.
2.4 Logical Nodes for control. LN Group: C
2.4.1 CSWI (Switch controller)
In the F650 there are up to 9 configurable switchgears. Currently nine XSWI and nine CSWI are implemented and mapped
to first nine switchgears in F650. XSWI and CSWI Logical Nodes can be seen as paired objects in F650 as one pair of XSWI
and CSWI map to the same switchgear. XSWI1 and CSWI1 map to Switchgear1, XSWI2 and CSWI2 map to Switchgear2,
etc. The difference between XSWI and CSWI in F650 is that control commands cannot be sent directly via XSWI LN. Control
commands have to be sent via CSWI LN.
In CSWI LN for "Pos" controllable attribute all possible control models are applicable:
• “direct-control-with-normal-security”
• “SBO-control-with-normal-security”
• “direct-control-with-enhanced-security”
• “SBO-control-with-enhanced-security”
The sboTimeout attribute for Pos is configurable in a range from 500 ms to 60 seconds.
AutoRecBlk INS Auto Reclosing Block Status E AR Block Mode
Settings
Rec1Tmms ING First Reclose Time O Dead Time 1
Units in miliseconds
Rec2Tmms ING Second Reclose Time O Dead Time 2
Units in miliseconds
Rec3Tmms ING Third Reclose Time O Dead Time 3
Units in miliseconds
Rec4Tmms ING Fourth Reclose Time E Dead Time 4
Units in miliseconds
RclTmms ING Reclaim Time O Reclaim Time
Units in miliseconds
MaxNumShot ING Max number of Shots E Max number Shots
RsTmms ASG Reclosing --> Ready E Reset Time
HoldTmms ASG Cond Check Time E Hold Time
CondEna SPG Check Cond (Enable, Disable) E Cond Permission
RRECEna SPG Function Enable, Disable E Function Permission
CSWI class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
CSWI Switch controller
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
NamPlt LPL Name plate M
Controls
Pos DPC Switch position M Switch open, close, undefined
