7-54 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
The sboClass attribute for Pos can only have value "0" (operate-once).
2.5 Logical Nodes for generic references. LN Group: G
2.5.1 GGIO (Generic process I/O)
2.5.1.1 GGIO
This logical node class is used is used to map digital and analogue inputs of I/O boards F, G, H and J.
GGIO class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
GGIO Generic process I/O
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
NamPlt LPL Name plate M
Status information
BoardSt SPS Board Status E Board Status.
True:
boar
d present and working correctly
False:
boar
d not present
boar
d present and board model
mismatch
boar
d present and hardware failure
Ind1 SPS General Indication ( binary input ) O Contact Input 1
Ind2 SPS General Indication ( binary input ) O Contact Input 2
Ind32 SPS General Indication ( binary input ) O Contact Input 32
Ind33 SPS General Indication ( binary input ) O Contact Output 1
.. .. .. .. ..
Ind48 SPS General Indication ( binary input ) O Contact Output 16
Measured Values
AnIn1 MV Analogue input O Analog Input 1
AnIn2 MV Analogue input O Analog Input 2
AnIn8 MV Analogue input O Analog Input 8
