CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-75
2.2.2.7 hsePTOC
This logical node class is used for sensitive ground time overcurrent function and has 3 instances inside the device.
2.2.2.8 NgSeqPTOC
This logical node class is used for negative sequence time overcurrent function and has 3 instances inside the device.
PTOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Time overcurrent
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start O TOC PKP
Op gePhsACT Operate M TOC OP
Blk geSPS Block O TOC BLK
Settings
PTOCEna geSPG_2 Function O
InMagTyp geING_0_2 Input O
StrVal geFloatASG_2 Pickup level O
TmACrv geCURVE_3 Curve O
TmMult geFloatASG_2 TD Multiplier O
RsMod geING_0_2 Reset O
SnpshtEvEna geSPG_2 Snapshot events enabled O
PTOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Time overcurrent
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start O TOC PKP
Op gePhsACT Operate M TOC OP
Blk geSPS Block O TOC BLK
Settings
PTOCEna geSPG_2 Function O
StrVal geFloatASG_2 Pickup level O
TmACrv geCURVE_3 Curve O
TmMult geFloatASG_2 TD Multiplier O
RsMod geING_0_2 Reset O
SnpshtEvEna geSPG_2 Snapshot events enabled O
