CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-77
2.2.4 PTOV (Overvoltage)
2.2.4.1 phsPTOV
This logical node class is used for phase overvoltage and has 3 instances inside the device
2.2.4.2 phsPTOV_2
This logical node class is used for phase overvoltage when setting group option is enabled and has 1 instance inside the
device.
PTOV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOV
Overvoltage
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Str PhsACD Start M TOV PKP
Op PhsACT Operate M TOV OP
Blk SPS Block O TOV BLK
Settings
PTOVEna SPG Function O
StrVal IntASG Start value O
OpDlTmms ING_8 Operate delay time O
RsDlTmms ING_8 Reset delay time O
PhLogic ING_0 Logic O
SnpshtEvEna SPG Snapshot events enabled O
PTOV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOV
Overvoltage
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Str PhsACD Start M TOV PKP
Op PhsACT Operate M TOV OP
Blk SPS Block O TOV BLK
Settings
PTOVEna SPG_2 Function O
StrVal IntASG_3 Start value O
OpDlTmms ING_8_2 Operate delay time O
RsDlTmms ING_8_2 Reset delay time O
PhLogic ING_0_2 Logic O
SnpshtEvEna SPG_2 Snapshot events enabled O
