7-78 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.2.4.3 auxPTOV
This logical node class is used for auxiliary overvoltage and has 3 instances inside the device.
2.2.4.4 auxPTOV_2
This logical node class is used for auxiliary overvoltage when setting group option is enabled and has 1 instance inside the
device.
PTOV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOV
Overvoltage
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Str Ge ne r a l A CD Start M TOV PKP
Op Ge n er a lA C T Operate M TOV OP
Blk SPS Block O TOV BLK
Settings
PTOVEna SPG_2 Function O
StrVal IntASG_3 Start value O
OpDlTmms ING_8_2 Operate delay time O
RsDlTmms ING_8_2 Reset delay time O
SnpshtEvEna SPG_2 Snapshot events enabled O
PTOV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOV
Overvoltage
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Str Ge ne r a l A CD Start M TOV PKP
Op Ge n er a lA C T Operate M TOV OP
Blk SPS Block O TOV BLK
Settings
PTOVEna SPG_2 Function O
StrVal IntASG_3 Start value O
OpDlTmms ING_8_2 Operate delay time O
RsDlTmms ING_8_2 Reset delay time O
SnpshtEvEna SPG_2 Snapshot events enabled O
