CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-79
2.2.4.5 neuPTOV
This logical node class is used for neutral overvoltage and has 6 instances inside the device.
2.2.4.6 neuPTOV_2
This logical node class is used for neutral overvoltage when setting group option is enabled and has 2 instances inside the
device. This logical node class is available only for firmware version below 7.50.
PTOV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOV
Overvoltage
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Str Ge n e ral ACD Start M TOV PKP
Op Gen e r alA C T Operate M TOV OP
Blk SPS Block O TOV BLK
Settings
PTOVEna SPG Function O
StrVal IntASG Start value O
OpDlTmms ING_8 Operate delay time O
RsDlTmms ING_8 Reset delay time O
SnpshtEvEna SPG Snapshot events enabled O
PTOV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOV Overvoltage
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Str Ge n e ral ACD Start M TOV PKP
Op Gen e r alA C T Operate M TOV OP
Blk SPS Block O TOV BLK
Settings
PTOVEna SPG_2 Function O
StrVal IntASG_3 Start value O
OpDlTmms ING_8_2 Operate delay time O
RsDlTmms ING_8_2 Reset delay time O
SnpshtEvEna SPG_2 Snapshot events enabled O
