7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.2.4.7 NgSeqPTOV
This logical node class is used for neutral sequence overvoltage and has 3 instances inside the device. This logical node
class has been included from firmware version 7.50.
2.2.5 PTRC (Protection trip conditioning)
For firmware version 7.00 or higher, this logical node shall be used to connect the operate outputs of one or more
protection functions to a common trip to be transmitted to XCBR logical node and has 1 instance inside the device.
2.2.6 PTUV (Undervoltage)
2.2.6.1 phsPTUV
This logical node class is used for phase undervoltage and has 3 instances inside the device.
PTOV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOV Overvoltage
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str geGeneralACD Start M TOV PKP
Op geGeneralACT Operate M TOV OP
Blk geSPS Block O TOV BLK
Settings
PTOVEna geSPG_2 Function O
StrVal geIntASG_3 Start value O
OpDlTmms geING_8_2 Operate delay time O
RsDlTmms geING_8_2 Reset delay time O
SnpshtEvEna geSPG_2 Snapshot events enabled O
PTRC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTRC Trip bus
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Op geGeneralACT Operate M
PTUV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTUV Undervoltage
Data
