CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-81
2.2.6.2 phsPTUV_2
This logical node class is used for phase undervoltage when setting group option is enabled and has 1 instances inside the
device.
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Str Ge n e ral ACD Start M TUV PKP
Op Gen e r alA C T Operate M TUV OP
Blk SPS Block O TUV BLK
StrPhGn PhsACD_1 Pickup Phase-Ground O
OpPhGn PhsACT_1 Operate Phase-Ground O
StrPhPh PhsACD_1 Pickup Phase-Phase O
OpPhPh PhsACT_1 Operate Phase-Phase O
Settings
PTUVEna SPG Function O
InMod ING_0 Mode O
StrVal IntASG Start value O
TmVCrv CURVE_2 Operating curve type O
TmMult FloatASG Time dial multiplier O
DeaLinVal IntASG Minimum Voltage O
PhLogic ING_0 Logic O
BkrMon SPG Supervised by 52 O
SnpshtEvEna SPG Snapshot events enabled O
PTUV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTUV Undervoltage
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Str Ge n e ral ACD Start M TUV PKP
Op Gen e r alA C T Operate M TUV OP
Blk SPS Block O TUV BLK
StrPhGn PhsACD_1 Pickup Phase-Ground O
OpPhGn PhsACT_1 Operate Phase-Ground O
StrPhPh PhsACD_1 Pickup Phase-Phase O
OpPhPh PhsACT_1 Operate Phase-Phase O
Settings
PTUVEna SPG_2 Function O
InMod ING_0_2 Mode O
StrVal IntASG_3 Start value O
TmVCrv CURVE_4 Operating curve type O
TmMult FloatASG_2 Time dial multiplier O
DeaLinVal IntASG_3 Minimum Voltage O
PhLogic ING_0_2 Logic O
BkrMon SPG_2 Supervised by 52 O
SnpshtEvEna SPG_2 Snapshot events enabled O
