7-82 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.2.6.3 AuxPTUV
This logical node class is used for auxiliary undervoltage and has 3 instances inside the device.
2.2.6.3 AuxPTUV_2
This logical node class is used for auxiliary undervoltage when setting group is anabled and has 1 instances inside the
device.
PTUV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTUV Undervoltage
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Str Ge ne r a l A CD Start M TUV PKP
Op Ge n er a lA C T Operate M TUV OP
Blk SPS Block O TUV BLK
Settings
PTUVEna SPG Function O
StrVal IntASG Start value O
TmVCrv CURVE_2 Operating curve type O
TmMult FloatASG Time dial multiplier O
SnpshtEvEna SPG Snapshot events enabled O
PTUV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTUV Undervoltage
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str geGeneralACD Start M TUV PKP
Op geGeneralACT Operate M TUV OP
Blk geSPS Block O TUV BLK
Settings
PTUVEna geSPG_2 Function O
StrVal geIntASG_3 Start value O
TmVCrv geCURVE_4 Operating curve type O
TmMult geFloatASG_2 Time dial multiplier O
SnpshtEvEna geSPG_2 Snapshot events enabled O
