CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-85
2.2.9.2 DirPDOP
This logical node class shall be used to model the directional overpower function and has three instances inside the
device.
2.2.9.3 WattPDOP
This logical node class shall be used to model the wattmeter ground overpower function and has six instances inside the
device.
PDOP class
Attribute
Name
Attr.
Type
Explanation M/O notes
PDOP Overpower
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start M
Op gePhsACT Operate M
Blk geSPS_1 Block O
S1Str gePhsACD_2 Start O Stage 1 PKP
S1Op gePhsACT_1 Operate O Stage 1 OP
S2Str gePhsACD_2 Start O Stage 2 PKP
S2Op gePhsACT_1 Operate O Stage 2 OP
Settings
PDOPEna geSPG_2 Function O
BlkCloseTmms geING_0_2 Blk time after close O
S1DirPwrAng geFloatASG_1_2 Dir Power Angle 1 O
S1StrVal geFloatASG_1_2 Stage 1 Tap O
S1OpDlTmms geING_0_2 Stage 1 Time O
S2DirPwrAng geFloatASG_1_2 Dir Power Angle 2 O
S2StrVal geFloatASG_1_2 Stage 2 Tap O
S2OpDlTmms geING_0_2 Stage 2 Time O
SnpshtEvEna geSPG_2 Snapshot events enabled O
PDOP class
Attribute
Name
Attr.
Type
Explanation M/O notes
PDOP Overpower
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start M
Op gePhsACT Operate M
Blk geSPS_1 Block O
SupStr gePhsACD_2 Start O
Settings
PDOPEna geSPG_2 Function O
OVStrVal geFloatASG_1_2 Voltage Pickup Level O
InMagTyp geING_0_2 Current Selection O
OCStrVal geFloatASG_1_2 OC Pickup level O
