CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-87
2.2.11 PDIS (Distance)
All logical node classes described in this section have been included from firmware version 7.50.
2.2.11.1 LodEncPDIS
This logical node class shall be used to model the load encroachment function and has three instances inside the device.
2.2.12 PRTR (Rotor Protection)
All logical node classes described in this section have been included from firmware version 7.50.
2.2.12.1 LockedPRTR
This logical node class shall be used to model the locked rotor function and has three instances inside the device.
PDIS class
Attribute
Name
Attr.
Type
Explanation M/O notes
PDIS Distance
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start M
Op gePhsACT Operate M
Blk geSPS_1 Block O
Settings
PDISEna geSPG_2 Function O
MinVoltage geFloatASG_1_2 Freq Rate Trend O
RisLod geFloatASG_2 Freq Rate Pickup O
AngLod geFloatASG_2 Freq Rate Min Volt O
OpDlTmms geING_8_2 Operation Delay O
RsDlTmms geING_8_2 Reset Delay O
SnpshtEvEna geSPG_2 Snapshot events O
PRTR class
Attribute
Name
Attr.
Type
Explanation M/O notes
PRTR Rotor Protection
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start M
Op gePhsACT Operate M
Blk geSPS_1 Block O
Settings
PRTREna geSPG_2 Function O
InMagTyp geING_0_2 Input O
LodCurrent geFloatASG_1_2 Full Load Current O
strVal geFloatASG_2 Pickup Level O
OpDlTmms geING_8_2 Operation Delay O
RsDlTmms geING_8_2 Reset Delay O
SnpshtEvEna geSPG_2 Snapshot events O
