7-88 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.3 Logical Nodes for protection related functions. LN Group: R
2.3.1 RDIR (Directional element)
2.3.1.1 phsRDIR
This logical node class is used for phase directional elements and has 3 instances inside the device.
2.3.1.2 phsRDIR_2
This logical node class is used for phase directional elements when setting group option is enabled and has 1
instance inside the device.
RDIR class
Attribute
Name
Attr.
Type
Explanation M/O notes
RDIR Directional Element
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Dir PhsACD Direction M
Op PhsACT Operate O
Blk SPS Block O
BlkIn Gen e r alA C T _1 Block Input O
Settings
RDIREna SPG Function O
ChrAng FloatASG Characteristic angle O
PolOpMod ING_0 Direction O
BlkMod ING_0 Block Logic O
BlkValV IntASG Minimum operating current O
VMemTms FloatASG Voltage Memory Time O
SnpshtEvEna SPG Snapshot events enabled O
RDIR class
Attribute
Name
Attr.
Type
Explanation M/O notes
RDIR Directional Element
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Dir PhsACD Direction M
Op PhsACT Operate O
Blk SPS Block O
BlkIn Ge n e ralA CT_ 1 Block Input O
Settings
RDIREna SPG_2 Function O
ChrAng FloatASG_2 Characteristic angle O
PolOpMod ING_0_2 Direction O
BlkMod ING_0_2 Block Logic O
BlkValV IntASG_3 Minimum operating current O
VMemTms FloatASG_1_2 Voltage Memory Time O
SnpshtEvEna SPG_2 Snapshot events enabled O
