CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-89
2.3.1.3 ndRDIR
This logical node class is used for neutral directional elements and has 3 instances inside the device.
2.3.1.4 ndRDIR_2
This logical node class is used for neutral directional elements when setting group option is enable and has 1 instance
inside the device.
RDIR class
Attribute
Name
Attr.
Type
Explanation M/O notes
RDIR Directional Element
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Dir NeutACD Direction M
Op NeutACT Operate O
Blk SPS Block O
BlkIn NeutACT_1 Block Input O
Settings
RDIREna SPG Function O
ChrAng FloatASG Characteristic angle O
PolOpMod ING_0 Direction O
PolQty ENG Polarizing quantity O
BlkMod ING_0 Block Logic O
BlkValV IntASG Minimum operating current O
SnpshtEvEna SPG Snapshot events enabled O
RDIR class
Attribute
Name
Attr.
Type
Explanation M/O notes
RDIR Directional Element
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Dir NeutACD Direction M
Op NeutACT Operate O
Blk SPS Block O
BlkIn NeutACT_1 Block Input O
Settings
RDIREna SPG_2 Function O
ChrAng FloatASG_2 Characteristic angle O
PolOpMod ING_0_2 Direction O
PolQty ENG_2 Polarizing quantity O
BlkMod ING_0_2 Block Logic O
BlkValV IntASG_3 Minimum operating current O
SnpshtEvEna SPG_2 Snapshot events enabled O
