CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-91
2.3.1.7 hseRDIR
This logical node class is used for sensitive ground directional elements and has 3 instances inside the device.
2.3.1.8 hseRDIR_2
This logical node class is used for sensitive ground directional elements when setting group option is enabled and has 1
instance inside the device. This logical node class is available only for firmware version below 7.50.
RDIR class
Attribute
Name
Attr.
Type
Explanation M/O notes
RDIR Directional Element
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Dir Gen e r a lA C D Direction M
Op Ge n e ralA CT Operate O
Blk SPS Block O
BlkIn Gen e r alA C T _1 Block Input O
Settings
RDIREna SPG Function O
ChrAng FloatASG Characteristic angle O
PolOpMod ING_0 Direction O
BlkMod ING_0 Block Logic O
BlkValV IntASG Minimum operating current O
SnpshtEvEna SPG Snapshot events enabled O
RDIR class
Attribute
Name
Attr.
Type
Explanation M/O notes
RDIR Directional Element
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Dir Gen e r a lA C D Direction M
Op Ge n e ralA CT Operate O
Blk SPS Block O
BlkIn Gen e r alA C T _1 Block Input O
Settings
RDIREna SPG_2 Function O
ChrAng FloatASG_2 Characteristic angle O
PolOpMod ING_0_2 Direction O
BlkMod ING_0_2 Block Logic O
BlkValV IntASG_3 Minimum operating current O
SnpshtEvEna SPG_2 Snapshot events enabled O
