7-92 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.3.2 RREC (Autoreclosing)
This logical node class is used for autorecloser and has 1 instance inside the device.
2.3.3 RBRF (Breaker failure):
For firmware versions 7.00 or higher, this logical node class is used for breaker failure and has 1 instance inside the device.
2.3.4 RFLO (Fault Locator):
For firmware version 7.00 or higher, this logical node class is used for fault locator and has 1 instance inside the device.
RREC class
Attribute
Name
Attr.
Type
Explanation M/O notes
RREC Autoreclosing Element
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
OpCls Ge n e ral A CT Direction M
AutoRecSt AutoRecStENS Operate M
AutoRecLo INS_1 Block O
AutoRecBlk INS_1 Block Input O
Settings
RRECEna SPG Function O
MaxNumShot ING_0 Max. Number Shots O
Rec1Tmms1 ING_8 Dead Time 1 O
Rec1Tmms2 ING_8 Dead Time 2 O
Rec1Tmms3 ING_8 Dead Time 3 O
Rec1Tmms4 ING_8 Dead Time 4 O
RclTmms ING_8 Reclaim time
CondEna SPG Cond. Permission
HoldTmms FloatASG_1 Hold Time
RsTmms FloatASG_1 Reset Time
RREC class
Attribute
Name
Attr.
Type
Explanation M/O notes
RBRF Breaker failure element
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
OpEx Gene r a l ACT Direction M
RFLO class
Attribute
Name
Attr.
Type
Explanation M/O notes
RFLO Fault locator element
Data
