CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-93
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
FltRprtTrg SPS_1 Fault Report Trigger O
ClrFltRprts SPS_1 Clear fault reports O
FltZ FloatCMV Fault impedance M
FltDiskm FloatMV_3 Fault distance in km O
RPriFlt FloatMV_2 Primary Fault Resistance O
XPriFlt FloatMV_2 Primary Fault Reactance O
RSeFlt FloatMV_2 Secondary Fault Resistance O
XSeFlt FloatMV_2 Secondary Fault Reactance O
RFault FloatMV_2 Fault Resistance O
FltTyp INS_1 Fault type O
FltRprtNum INS_1 Fault report number O
PreFltIaMod FloatMV_2 Prefault Ia module O
PreFltIaAng FloatMV_2 Prefault Ia angle O
PreFltIbMod FloatMV_2 O
PreFltIbAng FloatMV_2 O
PreFltIcMod FloatMV_2 O
PreFltIcAng FloatMV_2 O
PreFltIgMod FloatMV_2 O
PreFltIgAng FloatMV_2 O
PreFltIsgMod FloatMV_2 O
PreFltIsgAng FloatMV_2 O
PreFltVabMod FloatMV_2 O
PreFltVabAng FloatMV_2 O
PreFltVbcMod FloatMV_2 O
PreFltVbcAng FloatMV_2 O
PreFltVcaMod FloatMV_2 O
PreFltVcaAng FloatMV_2 O
PstFltIaMod FloatMV_2 Postfault Ia module O
PstFltIaAng FloatMV_2 Postfault Ia angle O
PstFltIbMod FloatMV_2 O
PstFltIbAng FloatMV_2 O
PstFltIcMod FloatMV_2 O
PstFltIcAng FloatMV_2 O
PstFltIgMod
FloatMV_2 O
PstFltIgAng FloatMV_2 O
PstFltIsgMod FloatMV_2 O
PstFltIsgAng FloatMV_2 O
PstFltVabMod FloatMV_2 O
PstFltVabAng FloatMV_2 O
PstFltVbcMod FloatMV_2 O
PstFltVbcAng FloatMV_2 O
PstFltVcaMod FloatMV_2 O
PstFltVcaAng FloatMV_2 O
Settings
RFLOEna SPG Function
Z1Mod FloatASG_1 Pos.Seq. Module
Z1Ang IntASG_1 Pos.Seq. Angle
Z0Mod FloatASG_1 Zero Seq. Module
Z0Ang IntASG_1 Zero Seq. Angle
LinLenkm FloatASG Line length
ShwFltHMI SPG Show fault in HMI
SnpshtEvEna SPG Snapshot Events enabled
PhCtPol SPG Phase CT Polarity
