7-94 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.3.5 RBDR (Disturbance recorder channel binary):
This node has been implemented in firmware version 7.20. This logical node class is used for providing the circuit
component and phase identification and has 1 instance inside the device. RBDR and RDRE logical nodes make available all
attributes needed for the COMTRADE file.
2.3.6 RDRE (Disturbance recorder function)
This logical node has been developed in firmware 7.20. This logical node class is used modelling the disturbance recording
function and has 1 instance inside the device. RBDR and RDRE logical nodes make available all attributes needed for the
COMTRADE file.
RBDR class
Attribute Name Attribute type Explanation M/O/C/E Notes
RBDR Disturbance recorder channel binary
Data
Common Logical Node Information
Mod ENC Mode M Status-only
Beh ENS Behaviour M
Health ENS Health M
NamPlt LPL Name Plate M
Status information
ChTrg SPS Channel triggered M
DigCh01 SPS E
… … … …
DigChn16 SPS E
RDRE class
Attribute Name Attribute type Explanation M/O/C/E Notes
RDRE Disturbance recorder channel binary
Data
Common Logical Node Information
Mod ENC Mode M Status-only
Beh ENS Behaviour M
Health ENS Health M
NamPlt LPL Name Plate M
Status information
RcdMade SPS Recording made M
FltNum INS Fault number M
OscTrg SPS Oscillo trigger E
CycRcd INS Cycles per record E
RcdNum INS Available records E
Settings
RDREEna SPG Oscillography function enable E
TrgPos ING Trigger position E
SmpCyc ENG Samples per cycle E
MaxNumRcd ING Maximum number of records O
RcdMod ENG Recorder operation mode O
SnpshtEvEna SPG Snapshot events enabled E
