CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-95
2.3.7 RSYN (Synchronism-check)
This logical node has been included from firmware 7.50. This logical node class is used modelling the synchrocheck
function and has 1 instance inside the device
RSYN class
Attribute
Name
Attr.
Type
Explanation M/O Notes
RSYN Synchronism-check
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
SynBlkIn geSPS_1 Block signal O
SynOp geSPS_1 Closing permission signal O
Rel geSPS Release M
SynCondOp geSPS_1 Closing perm. according to logic O
DLDBOp geSPS_1 Closing perm. in DLDB condition O
DLLBOp geSPS_1 Closing perm. in DLLB condition O
LLDBOp geSPS_1 Closing perm. in LLDB condition O
HzInd geSPS Frequency difference indicator O
BusHzHiLinHz geSPS_1 Busbar frequency > line frequency O
BusHzLoLinHz geSPS_1 Busbar frequency < line frequency O
Measured values
DifVClc geFloatMV Calculated difference in voltage O
DifHzClc geFloatMV Calculated difference in frequency O
Settings
RSYNEna geSPG Function O
DeaBusVal geFloatASG Dead bus value O
LivBusVal geFloatASG Live bus value O
DeaLinVal geFloatASG Dead line value O
LivLinVal geFloatASG Live line value O
DifV geFloatASG Difference voltage O
DifAng geFloatASG Difference angle O
DifHz geIntASG Difference frequency O
TotTmms geING_8 Total time of synch. process O
DLDBEna geSPG Dead line - dead bus permission O
LLDBEna geSPG Live line - dead bus permission O
DLLBEna geSPG Dead line - live bus permission O
SnpshtEvEna geSPG Snapshot events enabled O
