7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.4 Logical Nodes for control. LN Group: C
2.4.1 CILO (Interlocking):
For firmware version 7.00 or higher, this logical node class is used for interlocking the operations performed over the
switchgears and has 16 instances inside the device.
2.4.2 CSWI (Switch controller)
This logical node class is used for switchgears status and has 16 instances inside the device.
In the F650 there are up to 16 configurable switchgears. Currently sixteen XSWI and sixteen CSWI are implemented and
mapped to all switchgears in F650. XSWI and CSWI Logical Nodes can be seen as paired objects in F650 as one pair of
XSWI and CSWI map to the same switchgear. XSWI1 and CSWI1 map to Switchgear1, XSWI2 and CSWI2 map to
Switchgear2, etc. The difference between XSWI and CSWI in F650 is that control commands cannot be sent directly via
XSWI LN. Control commands have to be sent via CSWI LN.
• In CSWI LN for "Pos" controllable attribute all possible control models are applicable:
• "direct-control-with-normal-security"
• "SBO-control-with-normal-security"
• "direct-control-with-enhanced-security"
• "SBO-control-with-enhanced-security"
The sboTimeout attribute for Pos is configurable in a range from 500 ms to 60 seconds.
The sboClass attribute for Pos can only have value "0" (operate-once).
CILO class
Attribute
Name
Attr.
Type
Explanation M/O notes
CILO Switch controller
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status information
EnaOpn SPS Enable Open M
EnaCls SPS Enable Close
CSWI class
Attribute Name Attribute Type Explanation M/O/E Notes
CSWI Switch controller
Data
Common Logical Node Information
Mod ENC Mode M Status-only
Beh ENS Behaviour M
Health ENS Health M
NamPlt LPL Name plate M
Controls
Pos DPC Switch position M Switch open, close, undefined
Status Information
Loc SPS Local control behaviour O Local/Remote
For firmware version 7.20 or above
