CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-97
2.5 Logical Nodes for generic references. LN Group: G
2.5.1 GGIO (Generic process I/O)
2.5.1.1 GGIO
This logical node class is used is used to map digital and analogue inputs of I/O boards F, G, H and J.
GGIO class
Attribute
Name
Attr.
Type
Explanation M/O notes
GGIO Generic process I/O
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status information
BoardSt SPS_1 Board status O
Ind1 SPS Status contact input 1 O
Ind2 SPS Status contact input 2 O
.. .. .. ..
Ind32 SPS Status contact input 32 O
Ind33 SPS Status contact output 1 O
.. .. ..
Ind48 SPS Status contact output 16 O
Measured and metered values
AnIn1 FloatMV Analog input 1 O
AnIn2 FloatMV Analog input 2 O
.. .. ..
AnIn8 FloatMV Analog input 8 O
Settings
VThrldA IntASG_1 Voltage threshold A O
VThrldB IntASG_1 Voltage threshold B O
VThrldC IntASG_1 Voltage threshold C O
VThrldD IntASG_1 Voltage threshold D O
DbceTmmsA ING_0 Debounce time A O
DbceTmmsB ING_0 Debounce time B O
DbceTmmsC ING_0 Debounce time C O
DbceTmmsD ING_0 Debounce time D O
InTyp01 ING_0 Type input 1 O
InTyp02 ING_0 Type input 2 O
.. .. .. ..
InTyp32 ING_0 Type input 32 O
DlInTmms01 ING_0 Delay time input 1 O
DlInTmms02 ING_0 Delay time input 2 O
.. .. .. ..
DlInTmms32 ING_0 Delay time input 32 O
OutLogic01 ING_0 Logic output 1
O
OutLogic02 ING_0 Logic output 2 O
.. .. .. ..
OutLogic16 ING_0 Logic output 16 O
OutTyp01 ING_0 Type output 1 O
OutTyp02 ING_0 Type output 2 O
.. .. ..
