CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-99
2.5.1.2 vinGGIO
This logical node class is used is used to map the latched and self reset virtual Inputs.
Note:
Double control points operate on pairs of Virtual Inputs in a manner that one Virtual Input of the pair is set to "1" and the
other Virtual Input of the pair is set to "0".
For all controllable attributes in this logical node only "direct-control-with-normal-security" model of control is applicable
2.5.1.3 eveGGIO
This logical node class is used to map data from the list of any all internal digital states (PLC control events).
GGIO class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
GGIO Ge ner i c pro c ess I / O
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
NamPlt LPL Name plate M
Controls
DPCSO1 geDPC Double point controllable status
output
O Latched Virtual Input 1, 2
DPCSO2 geDPC Double point controllable status
output
O Latched Virtual Input 3, 4
.. .. .. .. ..
DPCSO16 geDPC Double point controllable status
output
O Latched Virtual Input 31, 32
SPCSO1 SPC Single point controllable status output O Latched Virtual Input 1
SPCSO2 SPC Single point controllable status output O Latched Virtual Input 2
.. .. .. .. ..
SPCSO32 SPC Single point controllable status output O Latched Virtual Input 32
SPCSO33 SPC Single point controllable status output O Self reset Virtual Input 1
SPCSO34 SPC Single point controllable status output O Self reset Virtual Input 2
.. .. .. .. ..
SPCSO64 SPC Single point controllable status output O Self reset Virtual Input 32
GGIO class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
GGIO Ge ner i c pro c ess I / O
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
NamPlt LPL Name plate M
Status information
