7-100 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.5.1.4 geRemoteInputsGGIO
This logical node class is used to map data from incoming GOOSE messages.
Ind1 SPS General Indication ( binary
input )
O Control Event 1
Ind2 SPS General Indication ( binary
in
put )
O Control Event 2
......... .......... ............... .......... ..............
Ind128 SPS General Indication ( binary
in
put )
O Control Event 128
Ind129 SPS General Indication ( binary
in
put )
O Switchgear 1 event 1
Ind130 SPS General Indication ( binary
in
put )
O Switchgear 1 event 2
Ind131 SPS General Indication ( binary
in
put )
O Switchgear 1 event 3
Ind132 SPS General Indication ( binary
in
put )
O Switchgear 1 event 4
Ind133 SPS General Indication ( binary
in
put )
O Switchgear 2 event 1
......... .......... ............... .......... ..............
Ind192 SPS General Indication ( binary
in
put )
O Switchgear 16 event 4
GGIO class
Attribute
Name
Attr.
Type
Explanation M/O notes
GGIO Generic process I/O
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status information
Ind1 SPS Remote digital input 1 O
Ind2 SPS Remote digital input 2 O
.. .. .. ..
Ind64 SPS Remote digital input 32 O
AnIn1 FloatMV Remote float input 1 O
AnIn2 FloatMV Remote float input 2 O
.. .. .. ..
AnIn8 FloatMV Remote float input 8 O
AnIn9 IntMV_1 Remote integer input 1 O
AnIn10 IntMV_1 Remote integer input 2 O
.. .. .. ..
AnIn16 IntMV_1 Remote integer input 8 O
Settings
OscTmms ING_0 Oscillation time remote inputs O
NumChgs ING_0 Number of transient changes O
