CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-101
2.5.1.5 geRemoteOutputsGGIO
This logical node class is used to map PLC digital states for outgoing GOOSE messages.
Note: In 650 relays data from all logical nodes can be sent through outgoing GOOSE messages. Apart from that, logical
node rouGGIO gives the ability to send through GOOSE digital states that are results of PLC logic equations. Mapping and
configuration of rouGGIO states should be done with Enervista650 software.
2.5.1.6 dcntGGIO:
For versions 7.00 or higher, this logical node is used for modelling the eight digital counters of F650 relay.
GGIO class
Attribute
Name
Attr.
Type
Explanation M/O notes
GGIO Generic process I/O
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status information
Ind1 SPS Remote digital output 1 O
Ind2 SPS Remote digital output 2 O
.. .. .. ..
Ind32 SPS Remote digital output 32 O
GGIO class
Attribute
Name
Attr.
Type
Explanation M/O notes
GGIO Generic process I/O
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status information
Cnt1 BCR_2 Digital counter 1 O
.. .. .. ..
Cnt8 BCR_2 Digital counter 8 O
CntBlk1 SPS_1 Digital counter 1 block O
.. .. ..
CntBlk8 SPS_1 Digital counter 8 block O
CntHi1 SPS_1 Digital counter 1 high O
.. .. ..
CntHi8 SPS_1 Digital counter 8 high O
CntEq1 SPS_1 Digital counter 1 equal O
.. .. ..
CntEq8 SPS_1 Digital counter 8 equal O
CntLo1 SPS_1 Digital counter 1 low O
.. .. ..
CntLo8 SPS_1 Digital counter 8 low O
