7-102 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.6 Logical Nodes for metering and measurement. LN Group: M
2.6.1 MMTR (Metering)
2.6.2 MMXU (Measurement)
CntUp1 SPS_1 Digital counter 1 up O
.. .. ..
CntUp8 SPS_1 Digital counter 8 up O
CntDwn1 SPS_1 Digital counter 1 down O
.. .. ..
CntDwn8 SPS_1 Digital counter 8 down O
CntSetPre1 SPS_1 Digital counter 1 set preset O
.. .. ..
CntSetPre8 SPS_1 Digital counter 8 set preset O
CntRst1 SPS_1 Digital counter 1 reset O
.. .. ..
CntRst8 SPS_1 Digital counter 8 reset O
CntFrzRst1 SPS_1 Digital counter 1 FreezeReset O
.. .. ..
CntFrzRst8 SPS_1 Digital counter 8 FreezeReset O
CntFrzCnt1 SPS_1 Digital counter 1 FreezeCount O
.. .. ..
CntFrzCnt8 SPS_1 Digital counter 8 FreezeCount O
MMTR class
Attribute
Name
Attr.
Type
Explanation M/O notes
MMTR Measurement
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Measured values
SupWh BCR O
SupVArh BCR O
DmdWh BCR O
DmdVArh BCR O
CntPsWh FloatMV_1 O
CntNgWh FloatMV_1 O
CntPsVArh FloatMV_1 O
CntNgVArh FloatMV_1 O
MMXU class
Attribute
Name
Attr.
Type
Explanation M/O notes
MMXU Measurement
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
