CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-103
2.6.3 MSQI (Sequence and imbalance)
2.7 Logical Nodes for switchgear. LN Group: X
2.7.1 XCBR (Circuit Breaker)
Measured values
TotW FloatMV Total active power (P) O
TotVAr FloatMV Total reactive power (Q) O
TotVA FloatMV Total apparent power (S) O
TotPF FloatMV Average power factor (PF) O
Hz FloatMV Line Frequency O
PPV FloatDEL Phase to phase voltages (VL1L2,...) O
PhV FloatPhsWYE Phase to ground voltages (VL1ER, ...) O
A FloatWYE Phase currents (IL1, ...) O
AuxV FloatCMV_1 Auxiliar Phase Voltage O
BusHz FloatMV_1
MSQI class
Attribute
Name
Attr.
Type
Explanation M/O notes
MSQI Measurement
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Measured values
SeqA FloatSEQ O
SeqV FloatSEQ O
XCBR class
Attribute
Name
Attr.
Type
Explanation M/O notes
XCBR Circuit breaker
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status information
Loc SPS Local operation M Local / Remote
OpCnt INS Operation counter M Breaker openings
SumSwARs O
CBOpCap CBOpCapENS Cicruit breaker operating
capa
bility
O
Controls
Pos DPC_1 Switch position M Breaker open, close
BlkOpn SPC_1 Block opening M Virtual output
BlkClr SPC_1 Block closing M Virtual output
Settings
ThAlSwA FloatASG_1 Maximum KI2t O
SumSwATmms FloatASG_1 KI2t Integ. Time O
ExNumTr IntASG_1 Maximum Openings O
ExNumTr1hr IntASG_1 Max.Openings 1 hour O
