CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-105
3. Common Data Class
3.1 Common Data Class for status information
3.1.1 Single Point Status (SPS)
3.1.2 Integer Status (INS)
SPS class (Single point status)
gsSPS
Attribute
Name
Attribute Type FC TrgOp Value/Value Range
M/O/C
DataAttribute
status
stVal Boolean ST dchg M
q BVstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC
O
geSPS_1
Attribute
Name
Attribute Type FC TrgOp Value/Value Range
M/O/C
DataAttribute
status
stVal Boolean ST dchg M
q BVstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC O
dataNs Vstring255 EX AC_DLN_M
INS class (Integer status)
geINS
Attribute
Name
Attribute Type FC TrgOp Value/Value Range
M/O/C
DataAttribute
status
stVal INT32 ST dchg M
q BVstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC
O
geINS_1
Attribute
Name
Attribute Type FC TrgOp Value/Value Range
M/O/C
DataAttribute
status
stVal Boolean ST dchg M
q BVstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC O
dataNs Vstring255 EX AC_DLN_M
